2021 Hot sale network camera 4mp Colorful Night vision ip66 outdoor poe cctv video security ip surveillance camera alarm system for Guangdong, China
2 years ago
218
Share
The technologies are important in manufacturing the product.As a kind of multi-functional 2021 Hot sale network camera 4mp Colorful Night vision ip66 outdoor poe cctv video security ip surveillance camera alarm system, it can be widely found in the application scenario(s) of CCTV Camera.
Comments
No comments received
Suppliers
Shenzhen LS VISION Technology Co., Ltd.
Audited supplierChina3YRS
Room 201-205, Floor 2, Building E, Longjing Sci-tech Park, No. 335 Bulong Road, Bantian Street, Longgang District, Shenzhen, 518055, Guangdong, P.R. China
Product details
Comments
We are specialized in manufacturing 2021 Hot sale network camera 4mp Colorful Night vision ip66 outdoor poe cctv video security ip surveillance camera alarm system, etc. for over many years. it is highly acclaimed by the clients for its unique features. Get in touch with us - call, fill in our online form or connect via live chat, we are always happy to help.
| Place of Origin: | Guangdong, China | Brand Name: | LSVision |
| Model Number: | LS-PD22201 | Warranty: | One Year Free, All Life Service |
| Special Features: | NIGHT VISION, Two-way Audio, Motion Detection, Vandal-proof, Waterproof / Weatherproof | Sensor: | CMOS |
| Style: | Dome Camera, BULLET CAMERA | Function: | Waterproof / Weatherproof, Wide Angle, NIGHT VISION, Two-way Audio, Alarm I/O, Built-in Mic |
| Video Compression Format: | H.265 | Data Storage Options: | NVR |
| Application: | Indoor, Outdoor | Customized support: | Online technical support, Customized logo, Software reengineering, OEM, ODM |
| Product name: | Security Video CCTV Camera | Lens: | Mstar Chip+1/3"" CMOS |
| IR Range: | 70-100 meters | Network protocol: | TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP |
| WDR: | 120dB true WDR technology | Network: | 1 RJ45 10M/100M adaptive Ethernet port |
| Power Supply: | Support POE 12 VDC ± 10% | Night vision: | Colorful Night vision |
| Storage: | Max 128GB TF/SD Card |
More Recommendation
Product Descritption
2021 Hot sale network camera 4mp Colorful Night vision ip66 outdoor poe cctv video security ip surveillance camera alarm system
Key Features :
Key Features :
Solution:Mstar Chip+1/3"" CMOS
1. 4MP , 2688x1520 @30fps
2. Standard Motorized lens 2.8-12mm
3. H.265, H.264, MJPEG, double streams
4. Built-in microphone, 120db WDR ,TF card slot
5.Cross line, intrusion(based on human body detection)
6. DC12V&POE, IR distance up to 40M
Model:LS-PD24401M
4MP (2560*1440)@ 30/25fps;
3MP (2304*1296) @30/25fps;
2MP (1920*1080) @30/25fps;
*Ultra 265, H.265, H.264, MJPEG
*2.8 ~ 12mm motorized zoom lens
*120dB true WDR technology enables clear image in strong light scene
*Support 9:16 Corridor Mode
*Built-in Mic
*Smart IR, up to 40m IR distance
*Supports 256 G Micro SD card
*IP67 protection
*Support PoE power supply
*3-Axis
Model:LS-PD22401
CMS Of IP POE Camera :
Specification
Model | LS-PD22201 |
Camera | |
Sensor | 1/2.7", 2.0 megapixel, progressive scan, CMOS |
Lens | 2.8mm@F2.0 |
DORI Distance | Lens (mm) 2.8 |
Detect (m) 42 | |
Observe (m) 16.8 | |
Recognize (m) 8.4 | |
Identify (m) 4.2 | |
Angle of View (H) | 112.9° |
Angle of View (V) | 59.1° |
Angle of View (O) | 121.2° |
Adjustment Angle | Pan: 0° ~ 360°,Tilt: 0° ~ 90°,Rotate: 0° ~ 360° |
Shutter | Auto/Manual, 1 ~ 1/100000s |
Minimum Illumination | Colour: 0.01Lux ( F2.0, AGC ON) |
0Lux with IR | |
Day/Night | IR-cut filter with auto switch (ICR) |
Digital Noise Reduction | 2D/3D DNR |
S/N | >52dB |
IR Range | Up to 20m IR range |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Defog | Digital Defog |
WDR | 120dB |
Video | |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
H.264 code profile | Baseline profile, Main profile, High profile |
Frame Rate | Main Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps |
Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; | |
Video Bit Rate | 128 Kbps~6144 kbps |
9:16 Corridor Mode | Supported |
OSD | Up to 4 OSDs |
Privacy Mask | Up to 4 areas |
ROI | Up to 8 areas |
Motion Detection | Up to 4 areas |
Image | |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital Noise Reduction | 2D/3D DNR |
Smart IR | Supported |
Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Dewarping | N/A |
HLC | Supported |
BLC | Supported |
Smart | |
Behavior Detection | Cross line, intrusion(based on human body detection) |
motion detection, tampering alarm, audio detection | |
General Function | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL, SNMP |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T) |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | |
Audio | |
Audio Compression | G.711 |
Suppression | Supported |
Sampling Rate | 8KHZ |
Storage | |
Edge Storage | Micro SD, up to 128GB |
Network Storage | ANR,NAS(NFS) |
Interface | |
Network | 10/100M Base-TX Ethernet |
Built-in Mic | Supported |
General | |
Power | DC 12V±25%, PoE (IEEE 802.3af) |
Power consumption: Max 7.0W | |
Material | Metal + plastic |
waterproof | IP67 |
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Product size/weight | Φ118 x 96mm/0.30kg |
Packing size/weight | 142 × 142 × 120mm/0.50kg |
Model | LS-PD24401M | |
Camera | ||
Sensor | 1/3", 4.0 megapixel, progressive scan, CMOS | |
Lens | 2.8 ~ 12mm, AF automatic focusing and motorized zoom lens | |
DORI Distance | Lens (mm):2.8,12M | |
Lens (mm):63,180 | ||
Observe (m):25.2,72 | ||
Recognize (m):12.6,36 | ||
Identify (m):6.3,18 | ||
Angle Of View (H) | 102.79°~ 30.86° | |
Angle Of View (V) | 54.50°~ 17.49° | |
Angle Of View (O) | 106.94°~35.49° | |
Adjustment Angle | Pan: 0° ~ 360°,Tilt: 0° ~ 90°,Rotate: 0° ~ 360° | |
Shutter | Auto/Manual, 1 ~ 1/100000s | |
Minimum Illumination | Support Easystar: Colour: 0.003Lux ( F1.6, AGC ON) | |
0Lux with IR | ||
Day/Night | IR-cut filter with auto switch (ICR) | |
Digital Noise Reduction | 2D/3D DNR | |
S/N | >56dB | |
IR Range | Up to 40m IR range | |
Wavelength | 850nm | |
IR On/Off Control | Auto/Manual | |
Defog | Digital Defog | |
WDR | 120dB | |
Video | ||
Video Compression | Ultra 265, H.265, H.264, MJPEG | |
H.264 Code Profile | Baseline profile, Main profile, High profile | |
Frame Rate | Main Stream: 4MP (2688*1520), Max 30fps;4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; | |
Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; | ||
Video Bit Rate | 128 Kbps~16 Mbps | |
9:16 Corridor Mode | Supported | |
OSD | Up to 4 OSDs | |
Privacy Mask | Up to 4 areas | |
ROI | Up to 8 areas | |
Motion Detection | Up to 4 areas | |
Image | ||
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |
Digital Noise Reduction | 2D/3D DNR | |
Smart IR | Support | |
Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise | |
Dewarping | N/A | |
HLC | Supported | |
BLC | Supported | |
Audio | ||
Audio Compression | G.711 | |
Suppression | Supported | |
Sampling Rate | 8KHZ | |
Storage | ||
Edge Storage | Micro SD, up to 256GB | |
Network Storage | ANR, NAS(NFS) | |
Smart | ||
Behavior Detection | Cross line, intrusion(based on human body detection) | |
motion detection, tampering alarm, audio detection | ||
General Function | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication | |
Network | ||
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, 802.1x, SNMP | |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T) | |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | ||
Interface | ||
Network | 10/100M Base-TX Ethernet | |
Built-in Mic | Supported | |
General | ||
Power | DC 12V±25%, PoE (IEEE 802.3af) | |
Power consumption: Max 8.50W | ||
Material | Metal | |
waterproof | IP67 | |
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |
Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |
Product size/weight | Φ129 x 110mm/0.66kg | |
Packing size/weight | 155 x 155 x 140mm/0.86kg | |
Customer Feedback
Our Factory
LS VISION
Shenzhen ls vision Technology Co., Ltd.
LS VISION focus on Security Surveillance Solutions since 2010.
We have awarded the title of “China High-Tech Enterprises”.
Combined with Monitoring Hardware and Software Equipment,
for the Global User to Provide Security, Smart Home Solution and Services.
The company is committed to the Smart Security and Smart Home Industry.
LS VISION Core Value: "Quality, Innovation, Dedication".
LS VISION Mission: "Creating a Safer&Green World".
Certifications
Exhibition
FAQ
1. who are we?
LS VISION Technology Co., Ltd. is a full HD Video Surveillance Solutions Provider. We have won the title of “China High Tech Enterprises”, ”Shenzhen High Tech Enterprises” and ”Member Unit of Shenzhen Smart Security Chamber of Commerce”.
LS VISION Technology Co., Ltd. is a full HD Video Surveillance Solutions Provider. We have won the title of “China High Tech Enterprises”, ”Shenzhen High Tech Enterprises” and ”Member Unit of Shenzhen Smart Security Chamber of Commerce”.
Main product line:IP Camera; NVR Kit; Wireless Home Camera; Solar Power Camera; PTZ Camera;Thermal imaging camera,temperature scanner camera.
Main Markets | Total Revenue(%) |
Eastern Europe | 20.00% |
South America | 10.00% |
Western Europe | 10.00% |
Central America | 10.00% |
Northern Europe | 10.00% |
Southern Europe | 10.00% |
North America | 5.00% |
Southeast Asia | 5.00% |
Africa | 5.00% |
Oceania | 5.00% |
Eastern Asia | 3.00% |
Domestic Market | 3.00% |
Mid East | 2.00% |
South Asia | 2.00% |
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
IP Camera,NVR Kit,Wireless Home Camera,Solar / PTZ Power Camera,AI Face Recognition Temperature Measuring Camera
4. why should you buy from us not from other suppliers?
LSVISION, China High Tech Enterprises. 15 years security R&D experience, supplier for Video Security Surveillance and Smart Home
Solution. support OEM and ODM. all products have passed CE, RoHS, FCC and ISO9001. more than 10 global exclusive agency.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
IP Camera,NVR Kit,Wireless Home Camera,Solar / PTZ Power Camera,AI Face Recognition Temperature Measuring Camera
4. why should you buy from us not from other suppliers?
LSVISION, China High Tech Enterprises. 15 years security R&D experience, supplier for Video Security Surveillance and Smart Home
Solution. support OEM and ODM. all products have passed CE, RoHS, FCC and ISO9001. more than 10 global exclusive agency.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
